Rear Axle Mount for 2000 Mercedes-Benz E430
No.
Part # / Description / Price
Price
10
Wheel Carrier
Mercedes-Benz
Mercedes-Benz Description: With lower control arm joint and wheel mounting,right.
MSRP $730.00
$546.25
MSRP $730.00
$546.25
20
Supporting Joint Mercedes-Benz
Mercedes-Benz Description: Left and right. Spring control arm to wheel bearing. Left suspension strut. Wheel carrier. Left spring link.
MSRP $72.00
$61.06
MSRP $72.00
$61.06
30
Angular Contact Bearing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
IS NO LONGER DELIVERED, ORDER DELIVERY CONTENTS
IS NO LONGER DELIVERED, ORDER DELIVERY CONTENTS
Description: Rear wheel bearing, left and right.
30
Collar Nut, Prop Shaft Mercedes-Benz
Mercedes-Benz Description: Left. Axle shaft to rear axle shaft flange m24x1.5.
MSRP $7.25
$5.81
MSRP $7.25
$5.81
80
MSRP $117.00
$98.00
80
MSRP $104.00
$86.80
140
MSRP $110.00
$92.40
140
MSRP $107.00
$89.60
160
MSRP $48.50
$39.15
200
Flat Head Screw Mercedes-Benz
Mercedes-Benz Description: M14x1.5x90. Spring control arm to wheel bearing left. Spring control arm to wheel bearing m 14x1,5x75.
MSRP $17.50
$14.18
MSRP $17.50
$14.18
220
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M14X1.5
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Tie rod to steering knuckle. Intermediate lever to pivot bearing. Trailer hitch to frame. Extension to rear subframe,front. Rod to spring control arm. Joint to steering knuckle left. Joint to steering knuckle m14 x 1,5. Joint to wishbone. Spring control arm to wheel bearing m14 x 1,5.
Diameter: 14mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm
Width across flats: 21mm. Tie rod to steering knuckle. Intermediate lever to pivot bearing. Trailer hitch to frame. Extension to rear subframe,front. Rod to spring control arm. Joint to steering knuckle left. Joint to steering knuckle m14 x 1,5. Joint to wishbone. Spring control arm to wheel bearing m14 x 1,5.
240
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: M12X1.5 X 90
Diameter: 12mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1,5mm. Spring control arm to rear subframe m 12x1,5x90. Spring control arm to rear subframe m12 x 1,5 x 90.
Diameter: 12mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1,5mm. Spring control arm to rear subframe m 12x1,5x90. Spring control arm to rear subframe m12 x 1,5 x 90.
MSRP $13.00
$10.26
MSRP $13.00
$10.26
240
260
Window Mercedes-Benz
Mercedes-Benz Description: Spring control arm to wheel bearing. Spring link to wheel carrier. Suspension strut to spring control arm at left. Hydropneumatic spring leg to spring control arm. Spring control arm to rear subframe.
MSRP $2.70
$2.16
MSRP $2.70
$2.16
260
MSRP $3.20
$2.57
280
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: Spring control arm to rear subframe. Upper transverse control arm to steering knuckle. Lower control arm to steering knuckle. Torsion bar to frame. Lower joint to control arm. Joint to steering knuckle. Shock absorber to lower control arm.
MSRP $7.50
$6.08
MSRP $7.50
$6.08
300
MSRP $9.50
$7.70
320
Screw Mercedes-Benz
Mercedes-Benz Description: Protective plate to spring control arm. Covering to spring control arm. Trim mount to left spring link. Mounting, cover. Guard to left spring link. Cover on spring link and thrust arm. At left side member.
MSRP $3.40
$2.70
MSRP $3.40
$2.70
360
MSRP $62.00
$52.54
370
MSRP $115.00
$96.60
380
Parts Kit, Tension Strut Mercedes-Benz
Mercedes-Benz Description: Camber strut. Mounting parts pushing strut.
MSRP $30.00
$24.30
MSRP $30.00
$24.30
410
Screw Mercedes-Benz
Mercedes-Benz Description: M16x1,5x70. Camber strut to left wheel carrier. Camber struts to wheel bearing. Thrust arm, camber strut and strut on rear subframe. Camber struts to wheel carrier.
410
Cap Screw Mercedes-Benz
Mercedes-Benz Description: M12x1.5x80. Camber struts to wheel carrier left. Thrust arm to wheel bearing to a 220 350 31 06. Camber struts to wheel bearing m 12x1,5x80.
MSRP $17.50
$14.18
MSRP $17.50
$14.18
420
Window Mercedes-Benz
Mercedes-Benz Description: Camber struts to wheel bearing. Camber struts to wheel carrier left.
MSRP $3.00
$2.43
MSRP $3.00
$2.43
420
Window Mercedes-Benz
Mercedes-Benz Description: Camber strut to left wheel carrier. Camber struts to wheel bearing. Thrust arm, camber strut and strut on rear subframe. Camber struts to wheel carrier.
450
MSRP $3.20
$2.57
540
MSRP $95.00
$79.80
550
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Repair size. Tie rod. With eccentric interior bushing left. For adjusting work only.
MSRP $142.00
$116.45
MSRP $142.00
$116.45
550
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Repair size. With eccentric interior bushing. Tie rod to rear subframe. Left and right.
MSRP $26.00
$20.93
MSRP $26.00
$20.93
570
Hex Nut W Clamping Part Mercedes-Benz
Mercedes-Benz Description: Upper transverse control arm to steering knuckle. M10. Tie rod to wheel bearing. Cross member, top, at steering knuckle, left. Upper control arm to frame.
650
Screw Mercedes-Benz
Mercedes-Benz Description: Thrust arm to wheel bearing left. Thrust arm to wheel bearing right.
680
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: THRUST ARM TO WHEEL BEARING RIGHT
Diameter: 16mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm.
Diameter: 16mm
Strength / hardness class: 10
Thread code letter: M
Thread pitch: 1,5mm.
690
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Chamber strut, strut and thrust arm to rear subframe. Propeller shaft to transmission m 12 x 1,5 x 60.
MSRP $11.00
$8.78
MSRP $11.00
$8.78
690
Hexagon Head Bolt Mercedes-Benz
Mercedes-Benz Description: Tension thrust camber struts to rear axle at left. M14x1.5x60. Camber struts to rear subframe. Chamber strut and strut to rear subframe.
720
MSRP $3.00
$2.43
No.
Part # / Description / Price
Price
30
Collar Nut, Prop Shaft Mercedes-Benz
Mercedes-Benz Description: Left. Axle shaft to rear axle shaft flange m24x1.5.
MSRP $7.25
$5.81
MSRP $7.25
$5.81
